Installing Orchestrator using Docker

1. System requirements

Minimum hardware required:

2 core CPU, 4 GB RAM

Environment:

Operating System: Any Linux-based OS with Docker support (for example, Linux Ubuntu 20.04+)
Docker 29.0.0 and Docker Compose 2.20.2 and higher (see Installing Docker section below for information on how to check if you have them installed)
Account for nexus.primo-rpa.ru:8000

Network configuration:

Open port: 5080 (Orchestrator UI) - the port can be changed if 5080 is occupied
Internet access is required temporarily to download Docker packages and images from the Primo RPA Nexus registry

2. Preliminary setup

Download the file docker-compose.yml from the release repository.
docker-compose.yml has the recommended version of components already preset. To specify a different version, configure the parameters below in 3 places in the file:

Specify the desired image version for each component. (Note that the repository address in the example below is given for illustration purposes only; contact technical support for the current address.)


    image: nexus01.s1.primo1.orch:8002/primo-rpa/orch-ui
    image: nexus01.s1.primo1.orch:8002/primo-rpa/orch-machine-info
    image: nexus01.s1.primo1.orch:8002/primo-rpa/orch-web-api
    image: nexus01.s1.primo1.orch:8002/primo-rpa/orch-robot-logs
    image: nexus01.s1.primo1.orch:8002/primo-rpa/orch-analytic
    image: nexus01.s1.primo1.orch:8002/primo-rpa/orch-notifications
    image: nexus01.s1.primo1.orch:8002/primo-rpa/orch-states
    image: nexus01.s1.primo1.orch:8002/primo-rpa/orch-log-events-webhook
    image: nexus01.s1.primo1.orch:8002/primo-rpa/orch-nuget2

Change the port if necessary in the ports section for the ‘orch-ui’ component:


    ports:
      - '5080:80' # Replace 5080 with the necessary port

alt

Specify the correct base-url with the same port:


    base-url: &base-url http://{server ip}:5080 # Use the same port as above

3. Installing Docker

ℹ️

For complete Docker installation and upgrade instructions, see the official documentation: Docker for Ubuntu

Primo RPA Orchestrator requires Docker and Docker Compose to be installed on the target machine.

Check if the correct versions of Docker and Docker Compose are already installed

Run the following commands:


  docker –version
  docker compose version

If the commands return version information, Docker and Docker Compose are installed. Continue with Verify Docker versions and Check Docker daemon status.
If Docker is not installed (for example, the command is not found), install Docker by following the instructions below (see Docker Installation subsection).

If Docker version is 29.0.0 or higher and Docker Compose version is 2.20.2 or higher then Docker is installed correctly and no action is required. If Docker version is lower than 29.0.0 or Docker Compose version is lower than 2.20.2, you must update Docker and Docker Compose by following the official Docker installation and upgrade instructions .

After upgrading, re-run the version check commands to confirm that the required versions are installed.

Check Docker daemon status

Ensure that the Docker service is running:


  systemctl status docker

If the service status is active (running), Docker daemon is operating correctly.
If the service is inactive or not found, start and enable Docker:


  sudo systemctl start docker
  sudo systemctl enable docker

After starting the service, verify its status again.

Docker Installation

If Docker has not been previously installed on your machine, run the commands below in your terminal to install it. During the installation, press Y if asked.


  # Updating packages
    sudo apt-get update
    sudo apt-get install -y ca-certificates curl

  # Adding official Docker repository
    sudo install -m 0755 -d /etc/apt/keyrings
    sudo curl -fsSL https://download.docker.com/linux/ubuntu/gpg -o /etc/apt/keyrings/docker.asc
    sudo chmod a+r /etc/apt/keyrings/docker.asc

echo \
  "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.asc] https://download.docker.com/linux/ubuntu \
  $(. /etc/os-release && echo "${UBUNTU_CODENAME:-$VERSION_CODENAME}") stable" | \
  sudo tee /etc/apt/sources.list.d/docker.list > /dev/null

# Installing Docker
    sudo apt-get update
    sudo apt-get install -y docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin

Verify the installation:

The Docker service starts automatically after installation. To verify that Docker is running, run the following commands in your terminal one by one:


  docker --version
  docker compose version
  sudo systemctl status docker

If you see version numbers and the Docker service is active (running) - everything is ready.

If the Docker service is not active, run the following command to start it manually (note that some systems may have this behavior disabled):


  sudo systemctl start docker

After starting the service, verify its status again.

4. Launching Orchestrator

⚠️

All commands (except docker login) must be run with root privileges or as sudo.

Login to the Primo Docker registry via docker login. You can request docker login credentials by contacting technical support.
```
docker login nexus.primo-rpa.ru:8000
```
Create the deployment directory:
```
sudo mkdir -p /opt/Docker
```
Upload your docker-compose.yml file to the directory using one of the options below:

Option 1: Upload via SCP (recommended for closed environments):

Upload the docker-compose.yml file to the server directory /opt/Docker.


  scp /path/to/docker-compose.yml user@server:/opt/Docker/

After uploading, verify that the file exists:


  ls /opt/Docker/docker-compose.yml

Make sure the file size is greater than zero and the file name matches exactly docker-compose.yml.

Option 2: Download from disk.primo-rpa using command line. (Note that the repository address in the example below is given for illustration purposes only; contact technical support for the current address.)

Example using curl:


curl -L --fail \
-o /opt/Docker/docker-compose.yml \
"https://disk.primo-rpa.ru/index.php/s/t9BHBjR6PP06Yax/download?path=%2FRelease%2FOrchestrator%2Ftools%2Fconfigs&files=docker-compose.yml"

Start containers:


cd /opt/Docker
sudo docker compose up -d

Check the status - all containers must be in the “Up” status:
```
sudo docker ps
```

5. Checking performance

After running the containers, open the following in your browser:

Orchestrator UI: http://your_server_ip:5080/

Verify via command line:


  curl -I http://your_server_ip:5080/

6. Configuring RDP2

Primo.Orchestrator.RDP2 service is not installed within Docker and needs to be installed separately using the instructions below:

In the RDP2 configuration, specify the IP and port of the server where Orchestrator is deployed (parameters EnabledOrigins, BaseUrl):


"EnabledOrigins": [
  "http://your_server_ip:5080"
],
"Orchestrator": {
  "BaseUrl": "http://your_server_ip:5080"
}

ℹ️

Orchestrator in a Docker container runs over HTTP. Make sure that the EnabledOrigins and BaseUrl parameters in the RDP2 settings specify the http:// protocol, not https://.

7. Updating the version

Stop the current version:
```
cd /opt/Docker
sudo docker compose down
```
Update image tags in docker-compose.yml
Start the new version:
```
sudo docker compose up -d
```
Clean up old images:
```
sudo docker image prune
```
